Voice & 3G Mobile Signal Booster- 600 sq.m.

(EE/O2/Vodafone/Three/T-Mobile and other providers)

  • Application:

    2 Band
  • Coverage:

    up to 600 sqm
  • Ideal For:

  • Provider:

  • Frequency:

    900/2100 MHz
  • Data:

    Calls & Data
Free Shipping In UK Delivery time: 5-7 Business Days

Benefits and Features:

  • Instant Signal Boost of up to 5 bars
  • CE & RoHS ISO Certified Product
  • Easy Installation
  • Instant Technical Assistance
  • 2 -Year Warranty

£ 339

Was £ 400. Save £ 61

Units Sold: 5602

Free Shipping

Overview

Kit includes:

  • 1x repeater
  • 1x outdoor Panel antenna
  • 1x indoor antenna
  • 1x power adapter
  • 1x 15 meters cable
  • 1x 5 meters cable
We provide 2 Years warranty on all our products
For better connection add LPDA antenna to your order.
Select Option
If our standard package cable lenght is not enought to cover your area you have an upgrade option.
Upgrade your booster kit with our internal antenna for optimal performance in larger spaces.
Price Match Guarantee

Our Dual Band is the most up-to-date solution for voice and 3G network boosting of 900 MHz and 2100 MHz signal amplification support. It is a dual-band repeater that provides a signal enhancement in a 600 sq. m. range. It can increase signal strength of 3 Mobile, O2, Vodafone and other UK major network providers with the help of this product. The signal booster can be installed in less than 15 minutes with our full installation kit and simple directions. You will be up and running in no time at all! The attractive design of our signal booster is paired with “5-bar” signal capability in urban or rural areas throughout the entire UK. Our 24/7 technical support staff is made up of trained professionals who are there to assist you with whatever you need. Our signal boosters and excellent service are the answers to all your signal problems!

  • Technical Sheet
  • Coverage
    up to 600 sqm
  • Use
    Suitable for areas from 300 to 600 sq.m.
  • Operator
    BT Mobile (3G)
    Giff Gaff (2G & 3G)
    O2 (2G & 3G)
    Talk Talk (2G & 3G)
    Tesco (2G & 3G)
    Vodafone (2G & 3G)
    Three (3G)
    EE (3G)
    T-Mobile (2G & 3G)
    Orange (3G)
    Virgin Mobile (3G)
  • Frequency
    900/2100 MHz
  • Number of simultaneous users
    75
  • Up-link
    890 ~ 915 MHz

    1920 ~ 1980 MHz
  • Down-link
    869~ 894 MHz
    2110-2170 MHz
  • Voltage
    AC90-264V,output DC 5V / 3A
  • Dimensions
    225*140*32 (mm)
  • Weight
    1.2 kg
  • Max Gain
    Up link :76db Downlink: 83dB
  • Bandwidth
    25 MHz / 60MHz
  • Ripple in Band
    ≤8dB
  • Max. Input Power Without Damage
    0 dBm
  • Output Power
    Up link :23 dBm Downlink: 27 dBm
  • Noise Figure @ max. gain
    Uplink:4.5db Downlink:8db
  • Return Loss
    ≤-8 dB
  • Time Delay
    ≤0.5 μs
  • MTBF
    > 20000 hours
  • Power Supply
    AC:90~265V, 50/ 60Hz;DC:5V 2A
  • Power Consumption
    ≤4W
  • Impedence
    50 Ω
  • RF Connector
    N -Female
  • Cooling
    Heat sink Convection cooling
  • Dimensions (L x W x H )
    225*140*32 (mm)
  • Weight
    1.2 KG
  • Installation Type
    Wall Installation
  • Environment Conditions
    IP40
  • Humidity
    <90%
  • Operating Temperature
    -10°C ~ 55°C
  • Power
    • Red
      Normal
    • Off
      DC power problem
  • DL (Downlink)
    • White
      No signal received Solution: Adjust the outdoor installation to get sound signal
    • Green
      Signal received ok but not perfect
    • Red
      Full signal received
  • UP (Uplink)
    • Flicker
      When there is a call it is normal
    • Green
      Always green means self-excited Solution: Turn off the booster, adjust the indoor and outdoor antenna again and try to expand the distance or create some barriers between them.
